Additional information: The CNC150 is an economical, simple to use control that incorporates the most popular features used in our 30-plus years experience in the pressbrake backgauging industry. It offers 150 job memory storage with up to 20 bends per job. The CNC150 will control any of the backgauge configurations allowing the operator to form the complete workpiece in one handling by controlling the backgauge, ram depth and gauge bar height of each bend. The CNC150 is our most popular control and is a simple low-cost way to improve your pressbrake productivity. Productivity increases of over 40% are typical when using this system over manual gauging. While simple, the CNC150 still offers enhanced features like reversal on pinch point and backgauge retract and delays. On 2-Axis hydraulic brakes backgauge retract on pinch point allows you to program the backgauge to retract once the workpiece is pinched in order to clear reverse bends.

1. Automec Cnc 150 Manual

The backgauge retract/delay feature allows the operator to program the backgauge to retract away from the die a specified time and distance to allow the operator time to reposition the workpiece. Both the time and distance of retract can be programmed separately for each bend. All electronics are housed in a single control panel featuring easy to read LED’s. The velvet-lexan front panel features high-feedback tactile feel pushbuttons.

A parts counter keeps track of total parts formed and can be viewed simply by pressing one button. When you release the button you automatically return to the program. A ram offset ±.393” and bend allowance of ±.393' can be programmed for each job to offset all dimensions in the program by the same amount. The CNC150 backgauge system comes with a two-year warranty. Additional Options: Add Ram Axis: Category 1 - Accurpress, Allsteel, Cincinnati, D&K, DiAcro, HTC, Hydrapower, Niagara, Pacific, Piranha, Standard, Tri-Acro, Wysong MTH, Wysong Rotary  $5,510.00 Category 2 - Adira up-acting, Amada, Guifil, Komatsu, Promecam  $6,765.00 Category 5 - Adira down-acting, AFM, Atlantic, Betenbender, Clausing, GFM, Heller, LVD, Wolf  $7,265.00 Category 6 - Accurpress ETS style control  $5,510.00 NOTE: GF-9 Fingers will be provided on low profile P models and GF-8 Fingers will be provided on all other models unless otherwise specified.

Prescriptive and Performance.

Add R-Axis: For G24B, G24HD (Programmable gauge Bar)  $5,510.00 For G48HD, G24TD (Programmable gauge Bar)  $6,265.00 For G48TD (Programmable gauge Bar)  $6,765.00 Additional Options: DP-4 Pendant Mount Assembly  $ 435.00. Extra Length Linear Scale (24” travel) for Cat 1 Ram Axis (add)  $ 520.00 Extra Pair GF-8 or GF-9 Finger Assembly  $ 570.00 G48 Rollaway Option (available only on G48 systems)  $ 5,635.00 G48 Tilt-Down Feature (available only on G48 systems)  $ 5,480.00 Pinch Point Switch Assembly  $ 660.00.NOTE: Standard ram scale is 12”. If ram travel exceeds 12”, the Extra Length 24” Linear Scale must be ordered.

FACTORY INSTALLATION: Standard 1-Axis or 2-Axis Category 1 Systems  $3,390.00 2-Axis Cat 2 and Cat 5, 3-Axis, G48, Triple Drive or Front/Rear Combo Systems  $3,750.00 Removal of Existing Backgauge  $ 785.00. Shipping We're able to obtain brokers for Cross country and worldwide deliveries and only hire fully insured Flatbed Double Drops, Single Drops and Permitted Loads. Make sure to get insurance, as this is not usually included.

All machines come banded and strapped to a pallet unless instructed otherwise. Crating is optional and comes at extra charge. Loading docks or ramps are required! If you do not have one, inform the shipping company and there will more than likely be an extra charge. Our Free Shipping Policy Our Free Shipping Policy only reflect on these brand new machines: Acra, Atek, Baileigh, Betenbender, Dake, Doall, Ez Cut Cnc, GMC, Knuth, National, Primeline, Rams, Scotchman, Tin Knocker, U.S Industrial, WellSaw (excludes Alaska and Hawaii).Not Applicable With Any Other Sale Prices, Loading docks or ramps are required! If you do not have one, inform the shipping company and there will more than likely be an extra charge. Free Shipping is on item over $2,500 only.

Residential Area with limited access will more than likely be an extra charge. Any questions or concerns please contact our staff (626) 444-0311. Important Note - Make sure to inspect all equipment deliveries for damages or problems. If any are present, mark them on bill of lading and inform driver. All Machines are FOB 'Freigh On Board'.

Customer is responsible for unloading equipment from truck ( By Means Of Forklift or Crane ).

One of the most affordable backgauges! Econogauge is an affordable manual backgauge solution for press brakes. It’s a manually positioned affordable backgauge for press brakes with a digital display that sells at a fraction of the price of a CNC backgauge. Automec of Waltham, Massachusetts has designed and manufactured CNC backgauges since 1972. Full-featured CNC backgauges include servo motors and electronics that allow the backgauge to move accurately to one or more sequential positions so workpieces can often be formed in a single handling. However, some of our budget-conscious customers that do mostly single dimension set-ups have asked for a more affordable backgauge.

With Econogauge, the operator simply loosens the carriage lock, slides the gauge bar to the proper position indicated on the digital display and relocks the carriage for a single backgauge dimension. An Affordable Backgauge Display The Econogauge display specifications:.56” Bright Red Led’s. Tactile Feel Keys. The Econoguage display resolves to.01”,.5mm or 1/32” fractions depending on operator preference.

Compact Control 8 ½” X 4” X 1 ½” The system utilizes many of the same components as our more sophisticated systems so cost-effective upgrades are possible if your needs increase. Contact factory for pricing. Econogauge is supplied with hardened work blocks which slide left to right in the 3 ½’ gauge bar. These are the primary contact surfaces to gauge your workpiece. Optional gauge flip fingers GF-1, GF-8 or GF-9 are also compatible with the Econogauge gauge bar and can be easily added to enhance the system’s capabilities.

Optional Gf-8 fingers Optional GF-9 Fingers Optional GF 1 Fingers Mechanical Specifications Weight. 26″ Depth 39″ Width 16″ Gauge bar length 3.5′ Gauge travel. 24″ Vertical height adjustment.

10″ Recommended pressbrake width up to 8′ Display Specifications Weight. 1.6 lbs Material Steel Max reading speed. 4′ (1.2 m) per second Display. 6 large 0.56″ LEDs Resolution 0.01″ Reading modes. Fraction, inch, decimal Input signal. Optical encoder Power. 9V DC 200 mA Dimensions.

Automec Cnc 150 Manual

8 ½” x 4″ x 1 ½” SUPPLIED: Affordable Backgauge, 3 ½ foot gauge bar, pair of workblocks, control, encoder, cables and mounting hardware. WARRANTY: (1) year. Post navigation.
